Filter Results

Some analyses in Cyclops produce multiple results per sample, the view analysis for example will produce a visibility score for each target material for each viewpoint in the analysis. The output from these types of analyses are therefore wrapped in a result object which can then be queried using the filter results component.

Typical result layout and output after filtering.

The component will automatically change into the corresponding filter type as a wire containing result objects is attached to the input. The Add/Update button on the component can then be used to generate a value list per filtering input with available filters.

Setting up the filter results component.

Detailed information about each result type can be found under the corresponding analysis page.

---
